| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Min. Illumination |
0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120dB |
| Day & Night |
ICR Cut |
| Linkage Method |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture. Trigger recording: memory card, network storage, pre-record and post-record. Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email. Trigger notification: HTTP, ISAPI, alarm output, Email |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Focus |
Fixed |
| Lens Type & FOV |
1.68mm @ F2.0, horizontal FOV 180°, vertical FOV 101°, diagonal FOV 180° |
| Aperture |
F2.0 |
| Lens Mount |
M12 |
| DORI |
Detect: 3.6 m, observe: 1.4 m, recognize: 0.8 m, identify: 0.4 m |
| IR Range |
20 m |
| Wavelength |
850nm |
| Smart Supplement Light |
Yes |
| Max. Resolution |
2688 × 1520 |
| Main Stream |
50Hz: 25fps (2688×1520, 2304×1296, 1920×1080, 1280x720) 60Hz: 24fps (2688×1520), 30fps (2304×1296, 1920×1080, 1280x720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264 /MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Stream Type |
Main stream, Sub-stream |
| Scalable Video Coding (SVC) |
H.264, H.265 |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host |
Up to 32 users; 3 levels: Administrator, Operator and User |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Network Storage |
micro SD/SDHC /SDXC (256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
Plug-in free live view: Chrome45.0+, Firefox52.0+; Local service: Chrome41.0+, Firefox30.0+ |
| Day/Night Switch |
Day, Night, Atuo, Schedule |
| Image Enhancement |
BLC;HLC;EIS;Lens Distortion;3D DNR |
| Image Settings |
Saturation; brightness; contrast; sharpness; rotate mode; white balance; AGC |
| SNR |
≥ 50 dB |
| Privacy Mask |
4 regions of privacy mask |
| On-board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Smart Event |
Line crossing detection, intrusion detecction, unattended baggage detextion, object removal detection, face detection, scene change detection |
| Web Client Language |
32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
privacy mask; heart; mirror; flash log; password reset via e-mail; pixel counter |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%; PoE: 802.3af, Class 3 |
| Power Consumption and Current |
12 VDC, 0.6 A, max. 7.2W; PoE: (802.3af, 36 V-57 V), 0.3 A to 0.2 A, max. 8.7W |
| Power Interface |
Φ5.5 mm coaxial power plug |
| Material |
Metal |
| Dimension / Weight |
Camera: Φ105 × 278 mm (Φ4.1″ × 10.9″); With package: 386×156×155 mm (15.20″ × 6.14″ × 6.10″); Camera: 570 g (1.26 lb.); With package: 760 g (1.68 lb.) |
| Class |
Class B |
| Protection |
IP67 |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
